Highlights:
- Microcontroller: STM32F401RCT6 with ARM® Cortex®-M4 core running at 84MHz.
- Memory: 256KB Flash memory and 64KB SRAM.
- Interfaces: Supports I2C, SPI, UART/USART, USB OTG, and SDIO.
- Power Supply: Accepts 3V to 5V via Type-C USB port.
- Compact Size: Measures approximately 54mm x 22mm.
Description:
The STM32F401RCT6 Development Board is a high-performance microcontroller platform designed for embedded system development. Featuring an ARM Cortex-M4 core running at 84MHz, it delivers efficient processing power suitable for various applications. Equipped with 256KB Flash memory and 64KB SRAM, the board provides ample storage for firmware and real-time data processing.
With multiple communication interfaces such as UART, SPI, I2C, USB OTG, and SDIO, this board offers flexibility for connecting peripherals. The Type-C USB power input ensures easy and reliable power delivery, supporting a voltage range of 3V to 5V. Its compact form factor makes it ideal for integration into small-scale embedded projects.
Features:
- Powerful STM32F401RCT6 MCU with ARM Cortex-M4 at 84MHz.
- 256KB Flash & 64KB SRAM for program storage and processing.
- Extensive communication interfaces:
- 3x USART/UART
- 3x SPI
- 3x I2C
- 1x USB OTG
- 1x SDIO
- 2x I2S
- 32 GPIO pins for peripheral connections.
- Supports input voltage from 3V to 5V for flexible power options.
- Compact design (54mm x 22mm) for easy integration.
- Operating temperature: -40°C to +85°C.
Packaging List:
- 1 x STM32F401RCT6 Development Board (with soldered headers)
